Description
Product Features
| :: | User Customisation for user’s flexibility like toggling of various modes from ppm, mg/l to % saturation, view electrode diagnosis, etc. |
| :: | Easy Calibration can be performed at 100% and/or 0% and mg/l or ppm against a known solution |
| :: | Automatic Temperature Compensation (ATC) guarantees the highest accuracy under varying temperature condition |
| :: | Galvanic Cell allows instantaneous measurements, producing quick responses and eliminates polarisation; requires minimal maintenance |
| :: | Automatically Compensates Salinity and Barometric Pressure after manual input for increased accuracy |
| :: | Hold Function momentarily freezes reading for easy viewing |
| :: | Auto-Power Off saves battery power after non-use |
| :: | Self-Diagnostic with message codes for easy troubleshooting |
| :: | Large Custom LCD provides optimum viewing even at a distance |
| :: | Protective Rubber Boot shields meter from accidental knocks and features a sturdy built-in stand for easy bench-top operation |
| :: | Rugged Carrying Case (Optional) provides handy on-site meter calibration and measurement |
Applications
Aquaculture: Use to monitor oxygen levels in catfish and shrimp farming; game stocking ponds; ornamental fish tanks and ponds; and in other fish farming applications.
Industrial: Ideal for checks the quality of plant water intake and discharge, wastewater and water treatment, recirculating systems and industrial process systems.
Environmental: Use to test water quality, monitor health of aquatic ecosystems, survey surface and ground water drinking supplies.
Educational: Ideal for quick, accurate DO readings in laboratories and schools.
Specifications
| Product Specification | Description |
| Dissolved Oxygen Range | 0 to 20.00 mg/l or ppm |
| Resolution & Accuracy | 0.01 mg/l or 0.01 ppm & ±1.5% Full Scale |
| % Saturation of Oxygen | 0.0 to 200/0 % |
| Resolution & Accuracy | 0.1% & ±1.5% Full Scale |
| Temperature Range | 0.0 to 50.0 °C (32 to 122 °F) |
| Resolution & Accuracy | 0.1 °C (0.1 °F) & ± 0.3 °C (0.5 °F) |
| Salinity Correction | 0.0 to 50.0 ppt |
| Barometric Pressure Correction | 500 to 1499 mmHg or 66.6 to 199.9 kPA |
| Method | Automatic correction after manual input |
| No. of Calibration Points | Up to 2 points; 100% in air and/or 0% in known solution |
| Special Functions | Self-diagnostic; Electrode characteristics; Hold & Auto-Power Off after20 minutes |
| Power Requirements | 4 x 1.4V batteries; > 700 hrs |
Order Information
|
Order No. |
Item |
| ECDO602PLUSK | Eutech DO 6+ Dissolved Oxygen Meter with 3m Cable Electrode ECDO6HANDY3M, 2 Assembled Membrane Cap Housing, 1 Refilling Electrolyte (10 ml) & Carrying Kit Set |
| ECDO601PLUSK | Eutech DO 6+ Dissolved Oxygen Meter with 1m Cable Electrode ECDO6HANDY3M, 2 Assembled Membrane Cap Housing, 1 Refilling Electrolyte (10 ml) & Carrying Kit Set |
